Do you understand capnography? Check yourself


This section can be used in two ways. If you saw a capnogram in the operating room today and you want to know what it is, identify the shape of the capnogram below and place the cursor over it to know the details. You can double click for a separate window showing details.

or,

Take the following quiz and see if you are right. For the answer place the cursor over the capnogram, or the answer box. You can double click for a separate window showing details.

Can all of the following waveforms be normal variants in infants and children?

J

/Clinicalapplication/Images/pd1.gif
/Clinicalapplication/Images/pd2.gif
/Clinicalapplication/Images/pd3.gif /Clinicalapplication/Images/pd4.gif
/Clinicalapplication/Images/responsecapn.gif

Yes

No




K

/Clinicalapplication/Images/carbonated.gif
/Clinicalapplication/Images/CO2absorbentexh.gif

L

/Clinicalapplication/Images/emphysema.gif /Clinicalapplication/Images/esophageal1.gif

M

/Clinicalapplication/Images/valveexp.gif /Clinicalapplication/Images/valvedefect.gif

N

/Clinicalapplication/Images/esophagealmask.gif

O

/Clinicalapplication/Images/lungtransplant.gif /Clinicalapplication/Images/startmonitor.gif

P

A decreases in cardiac output for a given ventilation, decreases the End-tidal PCO2.

True  False


Q

During an air embolism, what happens to the end-tidal PCO2 and the alveolar dead space?

End-tidal PCO2

Increase- Decrease


Alveolar dead space

Increase  Decrease
