(a-ET)CO2 difference and Alveolar dead space

Physiology of capnography

Bhavani Shankar Kodali MD

(a-ET)PCO2 reflects Alveolar Dead Space

alveolar dead space and arterial to end tidal CO2

(a-ET)PCO2 reflects alveolar dead space as a result of a temporal, a spatial and an alveolar mixing defect in the normal lung.

Normal values of (a-ET)PCO2 is 2-5 mm Hg.

(a-ET)PCO2 as an index of alveolar dead space

There is a positive relationship between alveolar dead space and (a-ET)PCO2. There is an exception to this rule (See text below)

(a-ET)PCO2 increases with age, emphysema, and in circumstances where alveolar dead space increases such as in low cardiac output states, hypovolemia, and pulmonary embolism.

(a-ET)PCO2 decreases in pregnancy and children (-0.65-3 mm Hg).

Decreased cardiac output increases alveolar dead space and thus increases (a-ET)PCO2

end tidal CO2 and hemorrhage

Air embolism increases alveolar dead space and thus increases(aET)PCO2
End tidal CO2 and air embolism
Pulmonary thrombo-embolism increases alveolar dead space and thus increases (a-ET)PCO2

end tidal CO2 and thrombo embolism

(a-ET)PCO2 may not reflect Alveolar Dead Space when phase III has a steeper slope
 (a-ET)PCO2 could be zero or negative even in the presence of alveolar dead space

end tidal CO2 and alveolar dead space

*This animation has been based on the concept as in reference 2.

(a-ET)CO2 gradient
as an index of alveolar dead space:

Under normal circumstances, the PETCO2 (the CO2 recorded at the end of the breath which represents PCO2 from alveoli which empty last) is lower than PaCO2 (average of all alveoli) by 2-5 mmHg, in adults.1-8 The (a-ET)PCO2 gradient is due to the V/Q mismatch in the lungs (alveolar dead space) as a result of temporal, spatial, and alveolar mixing defects. In healthy children, the (a-ET)PCO2 gradient is smaller (-0.65-3 mm Hg) than in adults.9-14 This is due to a better V/Q matching, and hence a lower alveolar dead space in children than in the adults.9 The (a-ET)PCO2 / PaCO2 fraction is a measure of alveolar dead space, and changes in alveolar dead space correlate well with changes in (a-ET)PCO2.4 An increase in (a-ET)PCO2 suggests an increase in dead space ventilation. Hence (a-ET)PCO2 is an indirect estimate of V/Q mismatching of the lung.

However, (a-ET)PCO2 does not correlate with alveolar dead space in all circumstances. Changes in alveolar dead space correlate with (a-ET)PCO2 only when phase III is flat or has a minimal slope. In this case, the area (blue shaded color in the figure above) rectangular and PaCO2 > PETCO2. However, if phase III has a steeper slope, the terminal part of phase III may intercept the line representing PaCO2, resulting in either zero or negative (a-ET)PCO2 even in the presence of alveolar dead space. Therefore, the (a-ET)PCO2 is dependent both on alveolar dead space as well as factors that influence the slope of phase III. This implies that an increase in the alveolar dead space need not be always be associated with an increase in the (a-ET)PCO2. The (a-ET)PCO2 may remain the same if there is an associated increase in the slope of the phase III. For example, it has been observed during cardiac surgery that alveolar dead space was increased at the end of cardiopulmonary bypass but as the slope of phase III was also increased, there was no change in (a-ET)PCO2.15,16

Cardiac output and (a-ET)PCO2

Reduction in cardiac output and pulmonary blood flow result in a decrease in PETCO2 and an increase in (a-ET)PC02. Increases in cardiac output and pulmonary blood flow result in better perfusion of the alveoli and a rise in PETCO2.17,18 Consequently alveolar dead space is reduced as is (a-ET)C02 The decrease in (a-ET)PC02 is due to an increase in the alveolar C02 with a relatively unchanged arterial C02 concentration, suggesting better excretion of C02 into the lungs. The improved C02 excretion is due to better perfusion of upper parts of the lung.18 Askrog found an inverse linear correlation between pulmonary artery pressure and (a-ET)PC02.18 Thus, under conditions of constant lung ventilation, PETCO2 monitoring can be used as a monitor of pulmonary blood flow.17,19


1 Kalenda Z. Mastering infrared Capnography. The Netherlands:Kerckebosch-Zeist, 1989.

2. Fletcher R. The single breath test for carbon dioxide. Thesis, Lund 1980.

3. Bhavani shankar K, Kumar AY, Moseley H, Hallsworth RA. Terminology and the current limitations of time capnography. J Clin Monit 1995;11:175-82.

4. Nunn JF, Hill DW. Respiratory dead space and arterial to end-tidal CO2 tension difference in anesthetized man. J appl Physiol 1960;15:383-9

5. Fletcher R, Jonson B. Deadspace and the single breath test carbon dioxide during anaesthesia and artificial ventilation. Br J Anaesth 1984;56:109-19.

6. Shankar KB, Moseley H,Kumar Y, Vemula V. Arterial to end-tidal carbon dioxide tension difference during Caesarean section anaesthesia. Anaesthesia 1986;41:698-702.

7. Fletcher R, Jonson B, Cumming G, Brew J. The concept of dead space with special reference to the single breath test for carbon dioxide. Br J Anaesth 1981:53:77-88.

8. Bhavani Shankar K, Mosely H, Kumar AY, Delph Y. Capnometery and anaesthesia. Review article. Can J Anaesth 617-32.

9. Fletcher R. Invasive and noninvasive measurement of the respiratory deadspace in anesthetized children with cardiac disease. Anesth Analg 1988;67:442-7.

10 Fletcher R, Niklason L, Drefeldt B. Gas exchange during controlled ventilation in children with normal and abnormal pulmonary circulation. Anesth Analg 1986;65:645-52.

11. Stokes MA, Hughes OG, Hutton P. Capnography in small subjects. Br J Anaesth 1986;58:814P.

12. Sivan Y, Eldadah MK, Cheah TE, Newth CJ. Estimation of arterial carbon dioxide by end-tidal and transcutaneous PCO2 measurements in ventilated children. Pediatric Pulmonology 1992;12(3):153-7

13 Burrows FA. Physiologic deadspace, venous admixture, and the arterial to end-tidal carbon dioxide difference in infants and children undergoing cardiac surgery. Anesthesiology 1989;70:219-25.

14 Cambell FA, McLeod ME, Bissonette B, Swartz JS. End-tidal carbon dioxide measurements in infants and children during and after general anaesthesia. Canadian J Anaesth 1993;41;107-10.

15. Fletcher R, Malmkvist G, Niklasson L, Jonson B. On line-measurement of gas-exchange during cardiac surgery. Acta Anaesthesiol Scand 1986;30:295-9.

16. Shankar KB, Moseley H, Kumar Y. Negative arterial to end-tidal gradients. Can J Anaesth 1991;38:260-1.

17. Leigh MD, Jones JC, Motley HL. The expired carbon dioxide as a continuous guide of the pulmonary and circulatory systems during anesthesia and surgery. J Thoracic cardiovasc surg 1961;41:597-610.

18. Askrog V. Changes in (a-A)CO2 difference and pulmonary artery pressure in anesthetized man. J Appl Physiol 1966;;21:1299-1305.

19. Weil MH, Bisera J, Trevino RP, Rackow EC. Cardiac output and end-tidal carbon dioxide. Crit Care Med 1985;13:907-9.
